Add spectroscopy to your microscope
508 PV™ Microscope Spectrometer
Add spectroscopy to your microscope
The 508 PV™ microscope spectrophotometer transforms your optical microscope or probe station by adding advanced spectroscopy and digital color imaging capabilities. It can also rejuvenate older microspectrometers with state-of-the-art optics, electronics, and software.
By attaching to an open photoport, the 508 PV™ enables the collection of transmission, reflectance, polarization, fluorescence, and luminescence spectra from microscopic samples with a well-equipped microscope. Featuring CRAIC's Lightblades™ spectrophotometer technology, it offers a broad spectral range from ultraviolet to near infrared. With the 508 PV™, you can swiftly and non-destructively acquire high-quality spectra from even sub-micron samples, ensuring ease of use and precision.
Perfect Vision for Science™
Introduction
Features
Key Features*
Add the 508 PV™ to any microscope or probe station for spectroscopy, colorimetry and micro spot film thickness.
- Featuring Lightblades™ spectrophotometers designed specifically for microspectroscopy
- User selected spectral range from deep UV to NIR
- 250 to 2100 nm available spectral range
- Permanently calibrated, variable measurement areas even below a micron
- Thermoelectric cooling available to improve signal-to-noise ratios and long term stability.
- Incorporates high resolution, color digital imaging...up to 6 megapixels available
- Featured with Lambdafire™ spectroscopy and imaging control and analysis software. Lambdafire™ also includes touchscreen control.
- Calibrated, variable measurement areas even smaller than a micron
- Transmission microspectroscopy
- Reflectance microspectroscopy
- Fluorescence microspectroscopy
- Polarization microspectroscopy
- Photoluminescence microspectroscopy
- Thin film thickness measurements
- Colorimetry of microscopic samples
- Refractive index measurements with the rIQ™ package
- Manual or fully automated operation
- Precision temperature control of samples
- Specialized software including statistical analysis, spectral databasing, image analysis and more
- NIST traceable microspectrometer standards
- Easy to use and maintain
- From the experts in microspectroscopy
UV-vis-NIR Microspectroscopy
Adding spectroscopy to your microscope™
The 508 PV™ is a spectrophotometer, incorporating an imaging system, designed to add to any microscope or probe station with a photoport. Configurable for work ranging from the deep UV through the visible and into the near infrared, this powerful tool gives your systems new capabilities including film thickness measurements and colorimetry. Featuring Lightblades™ technology, the 508 PV™ also allows you the ability to measure transmission, reflectance, polarization and photoluminescence spectra of even sub-micron samples. |  |
Photoluminescence
Cutting edge fluorescence & luminescence
| The 508 PV™ can be configured for fluorescence and luminescence spectroscopy of even sub-micron samples. Featuring Lightblades™ technology and with the ability to measure the fluorescence and luminescence from the UV to the NIR, the 508 PV™ is a powerful tool for photoluminescence analysis of materials sciences, biology, geology and more. |  |
Polarization
Polarization Microspectroscopy
| The 508 PV™ can be configured to acquire the polarization spectra of microscopic samples. Featuring Lightblades™ technology, the 508 PV™ polarization microspectroscopy capabilities allow you to acquire spectra of birefringent and other types of samples quickly and easily. |  |
Spectral Surface Mapping
Combines hardware and software for automated spectral analysis and 5D mapping of samples with microscopic spatial resolution. 5D maps of the absorbance, transmission, reflectance, fluorescence, emission and Raman spectra of samples may be generated. |  |
Imaging & Microscopy
High resolution color digital imaging
| The 508 PV™ features high resolution, color digital imaging with sophisticated software. It allows you to simultaneously see both the spectrophotometer entrance aperture and the sample. This makes it very easy to align the sample for measurements and to capture full color images under any measurement conditions. |  |
Applications
Applications
- Add spectroscopy to a microscope
- Add thin film thickness measurements to a probe station
- Upgrade an older microspectrophotometer
- Colorimetry of LCD and OLED displays
- Vitrinite reflectance of coal, coke and petroleum source rock
- Biotechnology research
Support
Support
CRAIC Technologies provides service and support for it's instruments worldwide. CRAIC Technologies service engineers offer instrument repair, maintenance, training and technical support for all aspects of CRAIC Technologies products.
The 508 PV™ microscope spectrophotometer is ideal for diverse applications such as colorimetry of pixels on flat panel displays, reflectometry of vitrinite coal and source rock, or thin film thickness measurements of optics and semiconductors. The 508 PV™is also a cost effective way to upgrade older microspectrometers to the latest hardware and software.
The 508 PV™ Microscope Spectrophotometer can be configured to acquire spectra from the deep ultraviolet to the near infrared. It can be added to a microscope to acquire spectra and images in absorbance, reflectance, and fluorescence.
The lit microscope base and the lit octagonal optical head are trademarks of CRAIC Technologies, Inc. CRAIC Technologies, 2030PV™, FLEX™, 508PV™, Apollo™, GeoImage™, rIQ™, Lambdafire™, Lightblades™ and "Perfect Vision for Science" are all trademarks of CRAIC Technologies, Inc. Instrument features offered depend upon instrument configuration. Features listed here may not be present in some configurations.
*Features and specifications depend upon instrument configuration. Specifications subject to change without notice.
